manufacturers prefabricated construction steel structure space frame used warehouse workshop buildings
Prefabricated construction using steel space frames is a popular
approach for designing and erecting warehouse and workshop
buildings. It combines the advantages of steel as a structural
material with the efficiency and speed of off-site fabrication,
resulting in a highly customizable, cost-effective, and
structurally sound building solution. Here's a closer look at
manufacturers, the prefabrication process, and the benefits of
using steel space frames for warehouse and workshop buildings.
Key Attributes
| Main Materials for Steel Structure Consturction |
| Item | Materials | Remark |
Steel
Frame | H section column and beam | Q345 steel, paint or galvanization |
| wind resistant column | Q345 steel, paint or galvanization |
Secondary bracing | Roof purlin | Q235B C/Z section galvanized steel |
| Wall purlin | Q235B C/Z section galvanized steel |
| Tie bar | Q235,φ89*3 round steel pipe |
| knee brace | angle steel,Q235,L50*4 |
| roof horizontal bracing | φ20,Q235B steel bar, paint or galvanized |
| column vertical bracing | φ20,Q235B steel bar, paint or galvanized |
| casing pipe | φ32*2.0,Q235 steel pipe |
| Pulling bar | Φ10 round bar Q235 |
Roof and wall
protecting system | Wall and roof panel | corrugated steel sheet/sandwich panel |
| gutter | color steel sheet/galvanized steel/stainless steel |
| Trim and flashing | color steel sheet |
| downspout | PVC |
| self tapping screw | |
Fastener system | Anchor bolts | Q235 steel |
| High strength bolt | The Specifications shall be determined according to the design of
steel structure. |
| Normal bolt | |
| Nuts | |
| Window and door | Window | Aluminium windows |
| Door | According to requirement to choose, can be EPS door, windproof
door, high-speed roll-up door, industrial sliding door etc. |
Company Profile
Juxin Group established for over 30 years, we have built strong technical backgrond team,advanced machinery & equipment,standard management system,perfect after-sale service we we have gathered rich experience on design, production,
installation, we have production an ability of mass order, Whatever
your need we will try our ulmost to meet your requiremt.
Product Description
Our main scope:
1. Steel Construct Multi & super high rise building(CBD Building).
2. Steel Construct Public buildings
3. Steel Construct Bridge
4. Steel Construct Workshop, Wareshouse, Farm
5. Steel Construct Residential Living Community.
6. Steel Construct Airport, Train Station.
Our advantage
Certifications
Customer Case
FAQ
Q1: What are the main products your company produces?
A: The business scope of my company is mainly structural steel
construction, such as industrial building, commercials building,
prefab house, etc. In addition, we also provide steel structure
processing service, like the processing of H- steel, steel beam,
color steel plate, C-Purlin steel, Z-Purlin steel , floor deck etc.
Q2: What are the benefits of steel construction?
A: 1-Durable and with long lifespan.
2-Short construction period than concrete and wooden building. 3-Low cost and reusable.
4-High strength and light weight, has good seismic performance.
5-Widely used for multi-purpose buildings.
Q3: What drawings will you supply?
A: Plan drawing, elevation drawing, sectional drawing, foundation
drawing, construction drawing and installation drawing.
Q4: What is your terms of payment?
A: L/C and T/T
